Delon Compact Gas Fired Steam Boilers 0.2–4.0 TPH – High Efficiency Industrial Steam Solutions

Delon Compact Gas Fired Steam Boilers 0.2–4.0 TPH – High Efficiency Industrial Steam Solutions

1. Introduction

In modern industries, steam is one of the most essential sources of energy. From food and beverage processing to textile manufacturing, from chemical plants to hospitality, the demand for safe, efficient, and reliable steam generation continues to increase. In many facilities, conventional steam boilers can be large, expensive to maintain, and often less efficient. For small to medium industries in particular, a compact, energy-efficient solution is the key to reducing operational costs while maintaining consistent production quality.

Delon Compact Gas Fired Steam Boilers are designed to meet these exact needs. Manufactured by Zhangjiagang Delon Thermal Machinery Co., Ltd., a trusted name in boiler manufacturing, and distributed in Indonesia through PT Indira Mitra Boiler, these steam generators provide a perfect combination of compact design, energy efficiency, safety, and durability.

Available in a wide capacity range from 0.2 TPH (200 kg/h) up to 4.0 TPH (4000 kg/h), the Delon Compact Series covers the needs of small laundries, food industries, beverage production lines, and even large-scale industrial processes such as palm oil refining, chemical processing, and textile dyeing.

This comprehensive catalog article will introduce each model, highlight their features, provide detailed specifications, and explain how they benefit various industries in Indonesia and beyond.

---

2. Why Choose Compact Gas Fired Steam Boilers?

When selecting a steam boiler, industries often face a trade-off between efficiency, safety, and cost. Traditional fire tube boilers, while widely used, tend to be bulkier and slower to start up. Compact water tube once-through boilers such as the Delon LSS Series overcome these challenges with modern engineering.

Advantages of Delon Compact Gas Fired Steam Boilers

1. High Thermal Efficiency
   All models are designed to achieve >88–91% efficiency, ensuring maximum energy utilization and reduced fuel costs.

2. Compact & Space-Saving Design
   The vertical once-through water tube structure allows for high output with a small footprint, ideal for industries with limited installation space.

3. Fast Steam Generation
   Compared to traditional fire tube designs, once-through boilers heat up much faster, delivering steam quickly for urgent production needs.

4. Safety as a Priority
   Each boiler is equipped with automatic pressure limit devices, flame monitors, water level alarms, and overcurrent protection. The PLC + LCD control system ensures real-time monitoring and safe operation.

5. Durability & Long Service Life
   Constructed from Q245R boiler steel, every weld undergoes 100% X-ray testing. With strong insulation and minimal heat loss, these boilers deliver reliable performance for many years.

6. Environmental Compliance
   The boilers are designed for low NOx emissions (≤45 mg/m³ for smaller models, ≤85 mg/m³ for larger models), meeting strict global environmental standards.

7. Flexible Fuel Options
   While optimized for natural gas, Delon boilers can also operate on LPG, city gas, or diesel oil depending on site requirements.

For businesses in Indonesia seeking energy savings, reliability, and environmental compliance, Delon Compact Gas Fired Steam Boilers are the ideal solution.

---

3. Delon Boiler Product Range (0.2–4.0 TPH)

Below is the detailed overview of each model within the Delon Compact Gas Fired Steam Boiler range.

---

3.1 Delon 0.2 TPH Steam Boiler (Model LSS0.2-1.25-Q)

The 0.2 TPH (200 kg/h) model is the entry-level compact steam boiler, perfect for small-scale industries such as laundries, small food processing units, and beverage production lines. Despite its compact size, it delivers high efficiency and reliability.

Key Features:

• Rated evaporation: 203 kg/h

• Pressure: 12.5 bar

• Efficiency: ≥91.5%

• Riello Burner (Italy)

• PLC + LCD control system

Technical Specifications:

Applications:

• Small food & beverage operations

• Industrial laundries

• Cosmetic and pharmaceutical labs

• Restaurants requiring steam sterilization

---

3.2 Delon 0.3 TPH Steam Boiler (Model LSS0.3-1.0-Q)

The 0.3 TPH (300 kg/h) model offers higher capacity while still maintaining compactness. It is a preferred choice for medium-sized garment factories, pharmaceutical industries, and beverage plants.

Key Features:

• Rated evaporation: 306 kg/h

• Pressure: 1.0 MPa

• Efficiency: ≥88%

• Riello 40 FS20 Burner

• Stainless steel feed water pump

Technical Specifications:

Applications:

• Textile & garment steaming

• Small chemical processes

• Medium-scale food & beverage lines

• Hotels and hospitals requiring sterilization

---

3.3 Delon 0.4 TPH Steam Boiler (Model LSS0.4-1.25-Q)

The 0.4 TPH (400 kg/h) model provides more robust output, making it suitable for industries like chemical production, packaging, and medium-scale textile facilities.

Key Features:

• Rated evaporation: 400 kg/h

• Pressure: 12.5 bar

• Efficiency: ≥91.3%

• Riello RS34 Burner (Italy)

• PLC automation with load regulation

Technical Specifications:

Applications:

• Chemical processing plants

• Food packaging industries

• Medium-scale textile dyeing units

• Beverage bottling operations

---

3.4 Delon 0.5 TPH Steam Boiler (Model LSS0.5-1.0-Q)

The 0.5 TPH (500 kg/h) model is the largest among the small-scale compact series, suitable for larger textile factories, palm oil processing, and industrial kitchens.

Key Features:

• Rated evaporation: 500 kg/h

• Pressure: 1.0 MPa

• Efficiency: ≥89.3%

• Riello RS34 Burner

• Stronger feed water pump (LEO, China)

Technical Specifications:

Applications:

• Palm oil refining & cooking oil industries

• Textile & garment manufacturing

• Food and beverage production lines

• Medium-sized chemical plants

---

3.5 Delon 1.0 TPH Steam Boiler (Model LSS1.0-Y.Q)

Moving into the 1.0 TPH (1000 kg/h) range, this model is ideal for larger food processing, textile factories, and industrial laundry systems.

Key Specifications:

• Evaporation: 1000 kg/h

• Pressure: 1.0 MPa

• Efficiency: ≥90%

• Gas consumption: ≈68 Nm³/h

Applications:

• Textile printing & dyeing

• Breweries and beverage plants

• Medium-scale palm oil refineries

• Food sterilization

---

3.6 Delon 1.5 TPH Steam Boiler (Model LSS1.5-Y.Q)

The 1.5 TPH (1500 kg/h) boiler is a mid-range industrial solution, popular among chemical plants, food industries, and textile mills.

Key Specifications:

• Evaporation: 1500 kg/h

• Efficiency: ≥90%

• Gas consumption: ≈102 Nm³/h

Applications:

• Chemical production plants

• Food & beverage processing

• Textile & garment factories

• Laundry for large hotels & hospitals

---

3.7 Delon 2.0 TPH Steam Boiler (Model LSS2.0-Y.Q)

The 2.0 TPH (2000 kg/h) steam boiler supports larger-scale industries that require continuous, stable steam supply.

Key Specifications:

• Evaporation: 2000 kg/h

• Efficiency: ≥90%

• Gas consumption: ≈136 Nm³/h

Applications:

• Oil refineries

• Food processing plants

• Large textile dyeing facilities

• Paper industries

---

3.8 Delon 3.0 TPH Steam Boiler (Model LSS3.0-Y.Q)

For heavy-duty operations, the 3.0 TPH (3000 kg/h) boiler provides powerful performance.

Key Specifications:

• Evaporation: 3000 kg/h

• Efficiency: ≥90%

• Gas consumption: ≈205 Nm³/h

Applications:

• Palm oil industries

• Large chemical plants

• Beverage and bottling industries

• Textile finishing mills

---

3.9 Delon 4.0 TPH Steam Boiler (Model LSS4.0-Y.Q)

The largest in the series, the 4.0 TPH (4000 kg/h) model is built for heavy industries requiring high and continuous steam output.

Key Specifications:

• Evaporation: 4000 kg/h

• Efficiency: ≥90%

• Gas consumption: ≈317 Nm³/h

Applications:

• Palm oil & refinery plants

• Chemical & petrochemical industries

• Large-scale textile factories

• Food & beverage mass production

---

4. Common Features Across All Models

• Riello Burner (Italy): World-class combustion technology.

• PLC + LCD Control: Easy, automatic, and safe operation.

• Water Pump (Stainless Steel): Reliable and durable.

• Energy-Saving Economizer: Lower fuel consumption.

• Strong Insulation: Reduced heat loss.

• Low NOx Emission: Environmentally friendly.

• Compact Design: Space-saving vertical structure.

---

5. Applications Across Industries

Delon boilers are used widely across:

• Food & Beverage (breweries, bottling, cooking oil, sterilization)

• Textile & Garment (dyeing, ironing, finishing)

• Pharmaceutical & Cosmetics (sterilization, extraction)

• Chemical & Oil Refinery (heating, distillation)

• Laundry & Hospitality (hotels, hospitals, large laundries)

---

6. Why PT Indira Mitra Boiler?

As the official distributor of Delon Boilers in Indonesia, PT Indira Mitra Boiler provides:

• Expert consultation

• Professional installation & commissioning

• Operator training

• Spare parts & after-sales service

With a strong presence across Indonesia, PT IMB ensures reliable support and timely delivery.

---

7. Conclusion & Call to Action

The Delon Compact Gas Fired Steam Boiler Series (0.2–4.0 TPH) offers unmatched flexibility, efficiency, and reliability for industries in Indonesia. Whether you run a small laundry or a large refinery, there is a Delon boiler tailored for your needs.
